XTnano – Version 10.04 – Configuration Manual

EVS Broadcast Equipment SA – January 2011

Issue

10.04.A

2.2.3 OSD SETTINGS

You can also define the OSD settings on page 1.1 or 5.1 of the setup menu on the

Remote Panel. You will find a description of these settings in the Multicam user

manual.

GENLOCK ERROR

Possible values: Yes (default) / No

This function enables or disables the Genlock information on the output monitor.

If Genlock reference is not correct, the “!GkV” message appears on the output

monitor.

DISK ERROR

Possible values: Yes (default) / No

This function displays an error message “!Raid” on the output monitor when a disk

is faulty.

Note

The server is equipped with a RAID disk array. This means that the

operation can continue seamlessly even with one faulty disk. If one disk

is disconnected during operation, the “!Raid” message appears on all

output monitors, and another message appears when the operator shuts

down the application, to invite him to replace the disk and rebuild the

RAID array.

Refer to the XTnano Tech Ref Hardware manual for details on the RAID

system and its maintenance.

AUDIO METERS ON OSD

Possible values: Yes (default) / No

This parameter enables/disables the display of audio meters at the bottom of each

output monitor.

AUDIO METERS ADJ.(DB)

Possible range: -83.2 dB to 0 dB. Default 0 dB

This parameter allows adjusting the sensitivity of audio meters on the OSD of the

output monitors. A positive value means that the meters will be more sensitive.
