Issue

10.04.A

XTnano – Version 10.04 – Configuration Manual

EVS Broadcast Equipment SA – January 2011

CHANNEL/DEVICE

This parameter specifies the channel that the GPI will affect or the device that

will send the GPI to the server.

A device can be an EVS Remote #1. If the operator selects EVS Remote #1, the

GPI will trigger the selected action on all channels controlled by that Remote

Panel.

FUNCTION

This parameter specifies the function that the GPI will trigger: Play, Pause,

Recue, Previous (recue to previous clip inside the playlist), Next (go to next clip

inside the playlist), Skip (skip the next clip in the playlist), -------- (no action is

taken) or Tally. For more information on the possible functions, refer to the

explanation on page 4 of the Setup Configuration in Multicam.

For the pinout of the GPI connector and wiring instructions, please refer to the XT

Tech Ref Hardware manual.

3.14.3 GPIS IN DELAY

GPI IN Settings p.8.4

GPI# Delay GPI# Delay

1[F1]Disable 5[F5]Disable

2[F2]Disable 6[F6]Disable

3[F3]Disable 7[F7]Disable

4[F4]Disable 8[F8]Disable

[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn

Possible values: Disable (default, immediate reaction), or 00s01fr to 02s00fr

This parameter defines the number of seconds and/or frames that the server will

wait after receiving the GPI IN signal to execute the GPI-related function.

3.14.4 GPIS OUT DEFINITION

GPI OUT Settings p.8.3

GPI# Function Type

1[F1]------------ [F5]------------

2[F2]------------ [F6]------------

3[F3]------------ [F7]------------

4[F4]Replace [F8]Open Pulse

[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
