EVS XT nano Configuration Manual

Issue
10.04.A
XTnano – Version 10.04 – Configuration Manual
EVS Broadcast Equipment SA – January 2011
26
Displayed Channels
For each source, you need to specify which recorder channel (CAM A to CAM C
max.) or player channel (PGM1 to PGM2 max.) available in the current channel
configuration should be displayed. If you select ‘None’, no image is displayed.
AUDIO MONITORING SETTINGS
In the Audio Monitoring from video field, you can select the channel for which
the audio can be monitored via the SDI outputs.
In the left-right track field, you can select the pair of stereo audio tracks of the
selected channel which should be monitored.
By default, the first stereo pair of the source displayed in the top left image is
selected.
ASPECT RATIO SETTINGS
In the Videos field of the Aspect Ratio group box, you can change the aspect
ratio of the video in HD. The following aspect ratios are available:
• 16:9 Anamorphic (default)
• Crop
• 4:3 aspect
In the SD downconverted field of the Aspect Ratio group box, you can change
the aspect ratio of the video in SD. The following aspect ratios are available:
• 16:9 Anamorphic (default)
• 4:3 Crop
• 4:3 Letterbox
DB15 OUTPUT SETTING
It is possible to configure the DB15 output and use one of the following formats:
• RGB HD (default)
• CVBS
If you use the CVBS format, the connected multiviewer
needs to be in full HD and to support the country-specific
frequency.
• YUV HD
