EVS XT nano Configuration Manual

XTnano – Version 10.04 – Configuration Manual
EVS Broadcast Equipment SA – January 2011
Issue
10.04.A
49
GPI Settings p.8.1
[F1]TTL GPIs set as : IN
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
When the TTL GPIs are defined as GPIs IN:
• The pages 8.2 to 8.4 include the settings for the 8 GPIs IN.
• The pages 8.5 and 8.6 include the settings for the 4 GPIs OUT.
When the TTL GPIs are defined as GPIs OUT:
• The pages 8.2 and 8.3 include the settings for the 4 GPIs IN.
• The pages 8.4 to 8.6 include the settings for the 8 GPIs OUT.
3.14.2 GPIS IN DEFINITION
If 8 GPIs IN are defined, the pages 8.2 and 8.3 include the settings for the GPI
inputs of the server.
GPI IN Settings p.8.2
GPI# Channel/Device Function
1[F1]PGM1 [F5]Play
2[F2]PGM2 [F6]Play
3[F3]-------------- [F7]--------
4[F4]-------------- [F8]--------
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
GPI IN Settings p.8.3
GPI# Channel/Device Function
5[F1]RMT1 [F5]Previous
6[F2]RMT1 [F6]Next
7[F3]RMT1 [F7]Skip
8[F4]-------------- [F8]Pause
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
For each GPI input, the operator has the possibility to define the following
parameters:
