Machine description – quick overview
Front view
16
099-005221-EW501
05.09.2016
Item
Symbol
Description 0
1
Carrying handle
2
Ready for operation signal light
Signal light on when the machine is switched on and ready for operation
3
Main switch, machine on/off
4
Cooling air inlet
5
Machine feet
6
Connection socket, “+” welding current
• ---------- MIG/MAG welding: welding current connection for the welding torch
• ---------- MIG/MAG cored wire welding: workpiece connection
• ---------- MMA welding: workpiece connection
7
"-" welding current connection socket
• MIG/MAG welding: Workpiece connection
• MMA welding: electrode holder connection
8
Machine control > see 4.3 chapter
9
Protective cap > see 5.1.4 chapter
10
Torch holder
