4-9 Hold mode (SQ-01 = 6)
1. General hold mode (FNC-11 = 0)
2. Peak hold mode ( FNC-11 = 1、2 )
3. Peak hold mode ( FNC-11 = 3、4 )
Peak hold mode with four different states ( FNC-11 = 1,2,3,4 ), positive peak weight(1), negative
peak weight, absolute value of peak weight and positive peak weight(2) . The peak holds of
absolute value and positive peak weight (2) both have no peak ready signal output.
Hold (Key / Ext.In)
Hold Release (Key / Ext.In)
ZERO
Hold (Key / Ext.In)
Hold Release (Key / Ext.In)
Normal display
Hold display
