EXCELL PRECISION CO., LTD
4-9-2 Hi, OK, Lo comparison
1. Normal HOLD ( FNC-11 = 0 )
Entering the Hold mode, Hi, OK, Lo comparison output. Escape Hold mode will switch off
the outputs.
2. Peak HOLD ( FNC-11 = 1, 2 )
If Peak Ready is ON, Hi, OK, Lo comparison output. Escape Hold mode will switch off the
outputs.
3. The absolute value of peak HOLD ( FNC-11 = 3 )
Entering the Hold mode, Hi, OK, Lo comparison output.
4. FNC-11 = 4
When the external input single Judgement is ON, Hi, OK, Lo comparison output.
5. If to release HOLD (display value and Hi, OK, Lo signal), please make HOLD release
signal on.
4-10 Totalizing (ACCU.) Auto / Transmit
With automatic totalising active (SQ-17) or RS232 / RS485 or BCD output set
to auto transmit.
1. SQ-01 = 1, 2, 4 or 5 batch / loss-in weight
a) When the weight reaches the Final weight and the batch finish signal is ON the net
weight will be added to the totaliser and number of additions is incremented. The
RS-232 / RS-485 and BCD outputs transmit data. (RS-01/ RS-02=10 accumulated
weight and counts)
b) When the net weight returns to the zero range (FNC-10), then the sequence in a)
above can be repeated.
c) When SQ-01=1 or 4, Net ＞Final and Batch finish=1, it accumulate once.
d) When SQ-01=2 or 5, -Net ＞Final and Batch finish=1, it accumulate once.
2. SQ-01 = 3 Comparison mode
a) When the net weight exceeds the zero range and the weight has stabilized it will be
added to the totaliser and number of additions is incremented. The RS-232 – RS-485
and BCD outputs transmit data.
3. SQ-01=6 HOLD mode
a).Lo. Wt. ＜weight＜Hi. Wt. weight will be added to the totaliser and number of additions
is incremented.RS-232 / RS-485 and BCD outputs transmit data. (RS-01/ RS-02=10
accumulated weight and counts)
b). Until the net weight returns to the zero range (FNC-10), then the sequence in a) above
can be repeated.
