Excell 120S - Page 41

040112XX
EXCELL PRECISION CO., LTD
ZSME400000004
40
Item
Function
Setting value
Default
Para-
meter
Description
RS1- 01
Transmit format
0
As display
0
1
Gross only
2
Net only
3
As display (simple)
4
Gross (simple)
5
Net (simple)
6
Comparison + As display (simple)
7
Comparison +Gross (simple)
8
Comparison +Net (simple)
9
Tare
10
Totalised (Accu.) Weight and number of
transactions
RS1- 02
Transmit mode
0
Transmit continuous + command mode
4
1
Auto transmit + command mode
2
Manual transmit + command mode
3
Command mode
RS1- 03
Transmit speed
0
600
4
1
1200
2
2400
3
4800
4
9600
5
19200
6
38400
7
57600
8
115200
RS1- 04
Parity
Bit length
Stop Bit
0
N, 8, 1
No parity, 8 data bits, 1 Stop bit
2
1
O, 7, 1
Odd parity, 7 data bits, 1 Stop bit
2
E, 7, 1
Even parity, 7 data bits, 1 Stop bit
MODBUS Mode: Parity
Bit length
Stop Bit
0
N, 8, 2
No parity, 8 data bits, 1 Stop bit
2
1
O, 7, 1
Odd parity, 7 data bits, 1 Stop bit
2
E, 7, 1
Even parity, 7 data bits, 1 Stop bit
RS1- 05
Transmit times
0
Open
0
1
1 time/sec.
2
2 time/sec.
3
5 time/sec.
4
10 time/sec.
RS1- 06
Transmission conditions
0 0 0 0 0 0
000000
Negative (Net Wt.)
Weight unstable
Overload (OL)
0  transmit cont.
1  Stop transmit
