5. Comparison condition (2)
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
Byte 0 : Zero Band
Byte 1 : Over
Byte 2 : Under / Hi
Byte 3 : SP1 / OK
Byte 4 : SP2 / Lo
Byte 5 : SP3
Byte 6 : Discharge
Byte 7 : Batch finished
Description
Output
ASCII
Description
Status 1
OL
4FH, 4CH
Over load
ST
53H, 54H
Weight stable
US
55H, 53H
Weight unstable
Status 2
GS
47H, 53H
Gross Weight
NT
45H, 54H
Net Weight
TR
54H, 52H
TARE
TW
54H, 57H
Totalised Weight
TN
54H, 4EH
Number of
transactions in
total
Data of Weight
0 ~ 9
30H ~ 39H
Figure of weight
+, -
2BH, 2DH
Symbol (+ or -) of
weight
Space
20H
Over load
.
2EH
Decimal
Units
Space, Space
20H, 20H
None
kg
6BH, 67H
kg
Space t
20H, 74H
tonne
lb
6CH, 62H
lb
Ending code
CR, LF
0DH, 0AH
Ending code
Separating code
,
2CH
Comma
ON
: 0
( ASC II Code 30 H )
OFF
: 1
( ASC II Code 31 H )
