Excell 120S User Manual

040112XX
EXCELL PRECISION CO., LTD
ZSME400000004
47
3. COMMAND FORMAT C
Host
Command + Data
<CR>< LF>
Slave
Command + Data
<CR>< LF>
Write weight compared value WS□□XXXXXX
XXXXXX : value (6 bytes) □□ : setting items
FW
Write target item of unload value
S1
Write SP1
S2
Write SP2
S3
Write SP3
UD
Write Under
LO
Write LO
ZB
Write Zero Band
HI
Write HI
PR
Write Peak value
OV
Write Over
BC
Write SQ14
PT
Set OUT
Note ： WSPTxxxxxx (input 0~255 decimal system) converts to BIT value which
indicates OUT (1-8) is ON, and the rest of numbers are OFF.
Ex:
Inputting WSPT000010 means the BIT value is 00001010 (OUT 2, 4 = ON) (OUT
1, 3, 5, 6, 7, 8 are OFF).
 Error messages
E1: Format command fault
E2: Setting parameters over range
E3: Command not recognised
 Indicator poling address
If address of RS1(2) – 07 is set to 0, after receiving the command, it executes
the command directly.
If address of RS1(2) – 07 is set to 1 ~ 99, after receiving the command, it
compares the address before the command. If it is correct, it then executes the
command.
For example: The indicator poling address is set to 02; it would send the weight
value only if it received the command:
@02RW＜CR＞＜LF＞
