BH3 Series
61
EXCELL PRECISION CO., LTD.
RS232 OUTPUT FORMAT
Format 1 (RS1 04 is set form 1 )
S T , G S , + 0 . 0 0 g CR LF
HEAD1 (3 byte)
S T , Stable
U S , Unstable
O L , Overload
HEAD2 (3byte)
G S , Gross Weight
N T , Net Weight
SIGN (1byte)
+ Positive weight
- Negative weight
DATA (8byte)
8 BYTES including the decimal point
UNITS (4byte)
g
c t
l b
o z
d r
G N
o z t
d w t
M M
t l . j
t l . T
t l . H
t
CR, LF (2byte)
CR LF
Total length of transmission is 21 bytes ( 3 + 3 + 1 + 8 + 4 + 2 = 21 )
HEAD1
SIGN
UNITS
HEAD2
To Next Page
