Excell BH3 Service Manual

BH3 Series
60
EXCELL PRECISION CO., LTD.
APPENDIX III RS232 BI-DIRECTION FORMAT
General Format
Gross S T , G S , + SP 1 2 3 . 4 5 6 SP SP SP g
Net S T , N T , + 1 2 . 3 4 . 5 6 SP SP c T
Tare S T , T R , + 0 1 2 . 3 4 5 6 SP SP k g
Overload O L , G S , + SP SP SP SP SP SP SP SP SP SP SP SP
Under
load
O L , G S , - SP SP SP SP SP SP SP SP SP SP SP SP
Unstable U S , G S , + 0 1 2 3 . 4 5 6 SP SP l b
CR LF
Format A
Host Command
Slave Command
MZ Zero CT Clear TARE value
MT Tare UA Shift to the 1st Unit
UB Shift to the second Unit UC Shift to the 3rd Unit
UD Shift to the 4th Unit UE Shift to the 5th Unit
UF Shift to the 6th Unit UG Shift to the 7th Unit
UH Shift to the 8th Unit UI Shift to the 9th Unit
UJ Shift to the 10th Unit UK Shift to the 11th Unit
UL Shift to the 12th Unit UM Shift to the 13th Unit
SC Serial printer output SA Auto Transmission Mode
SM Manual Transmit SO Command Mode
% Stop Continuous transmission and enter the command Mode
Format B
Host Command
Slave Data
RW Read the current Weight RT Read TARE
RG Read the Gross Weight RN Read Net weight value
Notes: Prior Camand plus %= Continuous read value
Prior command plus #= Read the stable value
EX:
Host %RW (Continuous Read)
Slave 5.185 (Continuous transmission)
Host #RW (Read the current weight value)
Slave 2.188
(Transmission after the balance is stable)
