3.3.1 Chain
The chain used for EXE-Rise chain hoist is in Zinc Galvanized Steel EN DIN 818-7 (grade of steel: 80).
There are five measures in order to hoist chain of destination:
CHAIN
SF-8
D8+
4x12 mm
D8 250 kg
D8+ 150 kg
6x18 mm
D8 500 kg
D8+ 300 kg
8x24 mm
D8 1000 kg
D8 2000 kg
D8+ 600 kg
D8+ 800 kg
D8+ 1200 kg
Table 8 “Chain measures”
Figure 5 “Chain dimensions”
Each chain has specific characteristics, among them the most important are reported:
Table 9 “Chain technical data”
LEGEND:
d
n
: nominal diameter – 1t: nominal pitch – bi
min
: minimum inner width – ba
max
: maximum outside width – Gauge length: 11t (11 links) –
ds
max
:maximum welding diameter – σ
min
: minimum stress at breaking force – F
min
: Minimum Breaking Force (MBF) – A
min
:minimum total
ultimate elongation – WLL: max Working Load Limit.
Chain can be identified from the manufacturers stamped identification marks on the chain. The stamps
shown are repeated at regular intervals along the length of the chain.
Figure 6 “Chain identification”
Permittance stamp Grade Type Manufacturing no. Batch no.
CHAIN 4x12
CHAIN 6x18
CHAIN 8x24
Code
XRC032-01M
XRC0618-01M
XRC0618-01M
Weight
0.35
0.78
1.39
d
n
[mm]
4.0
6.0
8.0
1t [mm]
12.0
18.0
24.0
bi
min
[mm]
5.0
7.2
9.6
ba
max
[mm]
13.7
20.2
27.0
Gauge length
[mm]
132.0
198.0
264.0
ds
max
[mm]
4.3
6.5
8.6
σ
min
[N/mm
2
]
800
800
800
F
min
[kN]
20.1
45.2
80.4
A
min
10 %
10 %
10 %
WLL [kg]
320
720
1280
