EXE RISE D8 - Bolts and Nuts

31 / 64
Figure 19 “Chain bag”
Table 15 “Chain bag dimensions”
Table 16 “Chain bag size”
3.3.11 Bolts and nuts
All bolts and nuts used in the line of forces, shall be fastened by means
of a torque wrench. Grade 8.8 bolts are used and the following torque
shall be applied.
Table 17 “Bolts”
SPECIFICATIONS
CHAIN BAG XS
CHAIN BAG S
CHAIN BAG M
CHAIN BAG L
CHAIN BAG XL
Litec Code
CHB029
CHB024
CHB025
CHB026
CHB027
External
Dimensions [cm]
14x9
20x17
20x17
20x17
27x21
Height [cm]
40
34
42
58
65
Selfweight [kg]
≈ 0.75
≈ 1.00
≈ 1.00
≈ 1.00
≈ 1.00
CHAIN
Up to 26m
@75%
(26-40)m
@75%
From to 40m
@75%
4X12
XS
XS
-
6X18
S
M
L
8X24
M
L
XL
8.8 bolts
Lbsft
Nm
M4
2
3
M5
4,5
6
M6
7,5
10
M8
18
25
M16
159
215
