EXE RISE D8 - Table 25 Spare Part of D8 1000 Kg DC;LVC, D8 2000 Kg DC;LVC and D8+ 600 Kg DC;LVC, D8

61 / 64
1000kg D8 DC/LVC and 600kg D8+ DC/LVC
2000kg D8 DC/LVC and 1200kg D8+ DC/LVC
Figure 22: “Spare Part of D8 1000kg DC/LVC, D8 2000kg DC/LVC and D8+ 600kg DC/LVC, D8+ 1200kg
DC/LVC”
Table 25: ““Spare Part of D8 1000kg DC/LVC, D8 2000kg DC/LVC and D8+ 600kg DC/LVC, D8+ 1200kg
DC/LVC”
CODE
DESCRIPTION
CODE
DESCRIPTION
COVER
GEAR BOX
COVER
ROTOR
BRAKE FLANGE
STATOR
GEAR BOX HOUSING
BRACKET
GEAR BOX FLANGE
FRAME BLOCK
LOAD WHEEL HOUSING
LIMIT SWITCH
LOAD WHEEL FLANGE
REVERSING CONTACTOR
MOTOR HOUSE
FUSES
BODY SWIVEL HOOK
RECTIFIER
CHAIN SWIVEL HOOK
TRASFORMER
CHAIN STOP
SCREW
EXTERNAL CHAIN GUIDE
LOAD WHEEL
DOUBLE BRAKE
