EXE RISE D8 - Table 24 Spare Part of D8 500 Kg DC;LVC And, D8+ 300 Kg DC;LVC

60 / 64
500kg D8 DC/LVC and 300kg D8+ DC/LVC
Figure 40: “Spare Part of D8 500kg DC/LVC and D8+ 300kg DC/LVC”
Table 24: “Spare Part of D8 500kg DC/LVC and D8+ 300kg DC/LVC”
CODE
DESCRIPTION
CODE
DESCRIPTION
COVER
GEAR BOX
COVER
ROTOR
BRAKE FLANGE
STATOR
GEAR BOX HOUSING
BRACKET
GEAR BOX FLANGE
FRAME BLOCK
LOAD WHEEL HOUSING
LIMIT SWITCH
LOAD WHEEL FLANGE
REVERSING CONTACTOR
MOTOR HOUSE
FUSES
BODY SWIVEL HOOK
RECTIFIER
CHAIN SWIVEL HOOK
TRASFORMER
CHAIN STOP
SCREW
EXTERNAL CHAIN GUIDE
LOAD WHEEL
DOUBLE BRAKE
