EXE RISE D8 - Figure 9 Lift Chain Hook with Safety Latch D8 2000 Kg and D8+ 1200 Kg

26 / 64
D8 2000 kg and D8+ 1200 kg
Figure 9. “Lift chain hook with safety latch” D8 2000 kg and D8+ 1200 kg
The standard ingress protection Level of IP55 means that when the hoist is used in wet environments,
adequate protection of the hoist body is required.
BODY SWIVEL HOOK
Body swivel hook is an assemblage of a plate with two holes, two fixing screws and hook (see Chain Swivel
Hook for models).
Figure 10. “Example of Body Swivel Hook”
EXE-Rise chain hoists with a lifting speed up to 8m/min generate a dynamic factor of 1.2 during start and
stop. Tolerances in lifting speed up to 5% can occur within same models of the same manufacture. Lifting
speeds vary depending on the load, and if the load is lifted or lowered.
DIMENSIONS [ mm ]
A
B
D
G
H
L
O
122
82
30
28
36
97
33
