MODEL D8+ DC / LVC
D8+ 150kg
D8+ 300kg
D8+ 600kg
D8+ 800kg - 1200kg
Hoist Specifications
Hoist Specifications
Hoist Specifications
Hoist Specifications
Hoist Specifications
Working Load Limit (WLL)
150kg
300kg
600kg
800kg
1200kg
Lifting Speed @50Hz
4m/min
4m/min
4m/min
4m/min
Motor Power
0.5kW
0.8kW
1.0kW
1.6kW
Operating Voltage Δ / Y
230/400VAC - 3 - 50Hz
230/400VAC - 3 - 50Hz
230/400VAC - 3 - 50Hz
230/400VAC - 3 - 50Hz
3 ph Δ 230 VAC Y 400 VAC
Δ 2.70A – Y 1.56A
Δ 3.29 A – Y 1.90 A
Δ 3.59 A – Y 2.07 A
Δ 4.59 A – Y 2.65 A
Falls of Chain
1
1
1
1
2
Load Wheel
5 pockets
5 pockets
5 pockets
5 pockets
Protection Class
IP55 DIN 40050
IP55 DIN 40050
IP55 DIN 40050
IP55 DIN 40050
FEM Classification
2m
2m
2m
2m
Duty Factor of Motor
40%
40%
40%
40%
Starts Per Hour
240
240
240
240
Connection Cable Lenght
1m
1m
1m
1m
Δ Power Supply Connector (*)
CEE 16A 9h 230VAC –
3PH + G blue plug
CEE 16A 9h 230VAC –
3PH + G blue plug
CEE 16A 9h 230VAC –
3PH + G blue plug
CEE 16A 9h 230VAC –
3PH + G blue plug
Y Power Supply Connector
CEE 16A 6h 400VAC –
3PH + G red plug
CEE 16A 6h 400VAC –
3PH + G red plug
CEE 16A 6h 400VAC –
3PH + G red plug
CEE 16A 6h 400VAC –
3PH + G red plug
Control Supply Connector
(only LVC)
CEE 16A 4h 24VAC –
3PH + G yellow socket
CEE 16A 4h 24VAC –
3PH + G yellow socket
CEE 16A 4h 24VAC –
3PH + G yellow socket
CEE 16A 4h 24VAC –
3PH + G yellow socket
Noise Level
67.5 db @ full load
67.5 db @ full load
67.5 db @ full load
67.5 db @ full load
DC Brake System
2
2
2
2
DC Brake Size
06
06
08
10
DC Brake Power
20W
20W
25W
30W
DC Brake Operating Voltage
105VDC
105VDC
105VDC
105VDC
DC Brake Rated Torque
4Nm
4Nm
8Nm
16Nm
DC Brake Rated Torque
Reduction at the speed specified
x% (1500r/min)
87% (1500 r/min)
87% (1500 r/min)
85% (1500 r/min)
83% (1500 r/min)
Clutch Characteristics
Clutch is friction based
force-limiter.Clutch outside
the line of kinetic
movement.
Clutch is friction based
force-limiter.Clutch outside
the line of kinetic
movement.
Clutch is friction based
force-limiter.Clutch outside
the line of kinetic
movement.
Clutch is friction based
force-limiter.Clutch outside
the line of kinetic
movement.
Limit Switch (only LVC)
Not Provided
4
4
4
Selfweight
≈ 17.0kg
≈ 24.0kg
≈ 43.0kg
≈ 43.0kg
≈ 45.0kg
Chain Specifications
Chain Specifications
Chain Specifications
Chain Specifications
Chain Specifications
Size
4x12mm
6x18mm
8x24mm
8x24mm
Safety Factor
10:1
10:1
10:1
10:1
Selfweight
0.35kg/m
0.78kg/m
1.39kg/m
1.39kg/m
Material
Zinc Galvanized Steel
grade 80
Zinc Galvanized Steel
grade 80
Zinc Galvanized Steel
grade 80
Zinc Galvanized Steel
grade 80
Chain Bag Specifications
Chain Bag
Specifications
Chain Bag
Specifications
Chain Bag
Specifications
Chain Bag
Specifications
(Chain Length Up to 26m) Size -
Selfweight - External dimension -
Height
XS - 0,75kg -
140x90mm - 400mm
S - 1,00kg -
200x170mm - 340mm
M - 1,00kg -
200x170mm - 420mm
M - 1,00kg -
200x170mm - 420mm
(Chain Length 26/40m) Size -
Selfweight - External dimension -
Height
XS - 0,75kg -
140x90mm - 400mm
M - 1,00kg -
200x170mm - 420mm
L - 1,00kg -
200x170mm - 580mm
L - 1,00kg -
200x170mm - 580mm
(Chain Length From to 40m) Size
- Selfweight - External dimension
- Height
Not Provided
L - 1,00kg -
200x170mm - 580mm
XL - 1,00kg -
270x2100mm - 650mm
XL - 1,00kg -
270x210mm - 650mm
