Operation
Theleverisusedtocontrolenginespeed.Movingthe
levertothefullforward(Choke)positionwillplace
theleverinthechokeposition.Thechokeaidsin
startingacoldengine.Movingthethrottlecontrol
forwardwillincreaseenginespeedandmovingitto
therearwilldecreaseenginespeed.
Thethrottle-choke-enginestopcontrolalsoincludes
anenginekillposition.Movingtheleverintothefull
rearward(Off)positionwillkilltheengine.
BladeControlLockLever
Thebladecontrollockleverislocatedontheright
sideofthehandlenexttotheBladeControlBailas
showninFigure4.
Movingthebladecontrollockleverintothefull
forwardpositionreleasesthebladecontrolbail.
Squeezingthebladecontrolbailagainstthehandle
engagestheblade.Releasingthebladecontrolbail
automaticallydisengagestheblade.Thebladecontrol
lockleverwillresettolockthebladecontrolbail.
FuelShut-OffValve
Thefuelshutoffvalveislocatedbetweenthe
carburetorandthefueltank.Thefuelshutoffvalve
shutsofftheowoffuelwhenthemachinewill
notbeusedforafewdays,whenparkinginsidea
building,andduringtransporttoandfromthejob.
Figure5
1.Fuelvalve
Rotatethevalve1/4turnclockwisetoshutofffuel.
Rotatethevalve1/4turncounterclockwisetoturn
onfuel.
Figure6
1.Rotateclockwisetoclose
2.Rotatecounterclockwisetoopen
Pre-Start
Fillfueltanks.SeeFuelRecommendationsin
theSpecicationssectionforadditionalgasoline
information.
DoNotaddoiltogasoline.
DoNotoverllfueltank.Fillthefueltanktothe
bottomofthellerneck.Theemptyspaceinthe
tankallowsgasolinetoexpand.Overllingmayresult
infuelleakageordamagetotheengineoremission
system.
Makesureyouunderstandthecontrols,their
locations,theirfunctions,andtheirsafety
requirements.
RefertotheMaintenancesectionandperformallthe
necessaryinspectionandmaintenancesteps.
OperatingInstructions
HandleAdjustment
Theheightofthehandlecanbeadjustedfor
comfortableoperation.Standbehindthehandleto
determinetheheight.Toadjustthehandleheight,
positionthehardwareintooneofthethreeholesin
thehandlebracket.
OpentheFuelShut-OffValve
Rotatethevalve1/4turncounterclockwisetoturn
thefuelon.
StartingtheEngine
1.Connectthewiretothesparkplug.
