Exmark 30" - Using the Mulch Plug; Using the Side Discharge Deflector

Operation
UsingtheMulchPlug
Occasionallyyoumaywishtousethemulchplugto
mulchthegrassandleafclippingsbackintothelawn.
•InstallingtheMulchPlug:
1.Stoptheengineandwaitforallmovingparts
tostop.
2.Ifthegrassbagisonthemower,removeit
(refertoRemovingtheGrassBag).Iftheside
dischargedeectorison,removeitandlower
thesidedischargedoor(refertoUsingthe
SideDischargeDeector).
3.Raisethereardischargedoorandinsertthe
mulchplugintothedischargeopening.The
plugwillsnapintothemowerhousing.
Figure15
1.Mulchplug2.Reardischargedoor
4.Lowerthedischargedoor.
•RemovingtheMulchPlug:
Note:Whengrassisthickandlush,clippings
maycollectonandaroundthedischargetunnel
plug.Thismaymakeitdifculttoremovethe
plug.Cleantheplugthoroughlyaftereachuse.
1.Stoptheengineandwaitforallmovingparts
tostop.
2.Raisethereardischargedoorandpullthe
mulchplugoutofthedischargetunnel.
3.Lowerthedischargedoor.
UsingtheSideDischarge
Deector
Usethesidedischargeforcuttingverytallgrass.
WARNING
Thebladesaresharp;contactingthebladescan
resultinseriouspersonalinjury.
Stoptheengineandwaitforallmovingpartsto
stopbeforeleavingtheoperatingposition.
•InstallingtheSideDischargeDeector:
1.Stoptheengineandwaitforallmovingparts
tostop.
2.Removethegrassbagifitisinstalledonthe
mower(refertoRemovingtheGrassBag).
3.Installthemulchplug(refertoInstallingthe
MulchPlug).
4.Liftandholdthesidedischargespringin
the“up”positionandpulloutwardonthe
dischargedoortoremove(see
Figure16).
Figure16
1.Sidedischargespring
3.Pulloutward
2.Liftandholdin“up”
position
4.Sidedischargedoor
5.Withthesidedischargespringheldinthe
“up”position,placethedischargedeector
ontothemowerhousingovertheopening.
Allowthespringtoloweroverthetabsonthe
dischargedeector.Makesurethedischarge
deectorissecurelyinplace(seeFigure17).
18
