Figure13
1.Frontquadrantblock
2.Cuttingheights
UsingtheGrassBag
•InstallingtheGrassBag
1.Releasethebladecontrollockleverandwait
forthebladeandallmovingpartstostop.
2.Ifthemulchplugisinstalledonthemower,
removeit(refertoRemovingtheMulchPlug).
Ifthesidedischargedeectorison,removeit
andinstallthesidedischargedoor(referto
UsingtheSideDischargeDeector).
3.Openthereardischargedoor.
4.Graspthehandleonthebagandsettherear
ofthebagframeontothehandlebracket
notch(
Figure14).
Figure14
1.Bag4.Handlebracketnotch
2.Handle5.Reardoor
3.Bagframe
6.Lower
5.Oncethebagisseated,lowertherear
dischargedoorontothebag.
•MowingwiththeGrassBag
WARNING
Aworngrassbagcouldallowsmallstones
andothersimilardebristobethrowninthe
operator’sorbystander’sdirection.Thrown
objectscanresultinseriouspersonalinjuryor
deathtotheoperatororbystanders.
Checkthegrassbagfrequently.Ifitis
damaged,installanewExmarkreplacement
bag.
Cutthegrassuntilthebagisfull.Toseeifthe
grassbagisfull,releasethebladecontrollock
leverandwaitforthebladetostop.Feelthebagto
determinewhetherthebagneedstobeemptied.
Note:DoNotoverllthebag.
•RemovingtheGrassBag
1.Releasethebladecontrollockleverandwait
forthebladeandallmovingpartstostop.
2.Raisethereardischargedoorandgraspthe
handleonthebag.
3.Liftthebagoffofthelawnmowerandlower
thereardischargedoor.
4.Graduallytipthebagforwardtoemptythe
clippings.
5.Toinstallthebag,refertothesectionon
InstallingtheGrassBag.
DANGER
Ifthereardischargedoordoesnotclose
completely,thelawnmowercouldthrow
objects.Thrownobjectscanresultin
seriouspersonalinjuryordeathtothe
operatororbystanders.
•Neveropenthedoortotherear
dischargeopeningwhenthebladesare
stillmoving.
•Ifyoucannotclosethedoorbecause
thegrassclippingsclogthedischarge
area,stoptheengineandgentlymove
thedischargedoorhandlebackand
forthuntilyoucanclosethedoor
completely.Ifyoustillcannotclosethe
door,removetheobstructionwitha
stick,notyourhand.
