Exmark 790 - ROPS Assembly

ROPS ASSEMBLY – 116-0230
-17-
Item Part No. Description Qty.
3 109-6653 Spacer ................................................... 2
4 116-0019 Asm, Rops Upper W/Decal .................... 1
4:2 107-2102 Decal, Warning, Folding Rops ............... 1
5 109-5337 Bumper, Rops ........................................ 2
6 116-0104 Asm, Spring Pin ..................................... 2
7 99-5107 Nut, Lock 1/2-13 .................................... 6
Item Part No. Description Qty.
8 3233-10 Bolt, Carriage 1/2-13 x 3 1/2 .................. 2
9 325-17 Screw, HH 1/2-13 x 4 ............................. 4
10 1-513435 Washer, Spring Disc 1/2 ........................ 4
11 109-9233 Bumper, Rubber Push-In ....................... 1
12 116-0090 Decal, Caution Fuel Vent ....................... 1
13 116-0960 Spacer ................................................... 2
