HEIGHT OF CUT ASSEMBLY – 109-7438
-21-
Item Part No. Description Qty.
1 62-1330 Bolt-Shoulder ......................................... 1
2 109-7130 Grommet................................................ 1
3 104-8301 Nut, Nyloc 3/8-16 Flg ............................. 1
4 109-7124 Spring, Extension ................................... 1
5 109-7128 Rod, Transport Lock .............................. 1
Item Part No. Description Qty.
6 116-0118 Pawl, Transfer Lock ............................... 1
7 109-7335 Asm, Hoc Plate W/Decal ....................... 1
7:2 116-0752 Decal, Cut Of Height .............................. 1
8 109-8250 Grip, Lever ............................................. 1
