Exmark 790 - Deck Idler Assembly

DECK IDLER ASSEMBLY – 109-2883
-15-
Item Part No. Description Qty.
1 43-0940 Spacer-Hub, Blower ...............................1
2 103-2916 Guard, Top............................................. 1
3 103-3504 Bearing, Spherical.................................. 2
4 103-3505 Seal, Double Lip .................................... 1
5 103-3506 Seal, Single Lip ...................................... 1
6 103-8743 Pulley, Idler 5"Flanged ........................... 1
7 106-7159 O-Ring ...................................................2
Item Part No. Description Qty.
9 109-7399 Pin, Spring Anchor ................................. 1
10 109-6658 Nut, Nyloc 3/8-16 Flg ............................. 2
11 109-7409 Screw, Shoulder 3/8-16 x 5 .................... 1
12 323-8 Screw, HH 3/8-16 x 1 1/2 ....................... 1
13 32120-10 Ring, Retaining ...................................... 2
14 302-19 Zerk, 1/4-28 Str...................................... 1
