Exmark 790 - Brake Handle Assembly

BRAKE HANDLE ASSEMBLY – 117-0383
-25-
Item Part No. Description Qty.
1 99-5107 Nut, Lock 1/2-13 .................................... 1
2 117-0380 Spacer ................................................... 1
3 115-3580 Arm, Brake LH ....................................... 1
4 117-0376 Spring Torsion RH ................................. 1
5 115-3574 Plate-Latch ............................................ 1
6 104-7201 Nut, Nyloc 1/4-20 Flg ............................. 1
7 117-0382-03 Brake Handle Asm ................................ 1
8 114-1207 Washer, Special .................................... 1
9 114-8187 Spring-Compression .............................. 1
Item Part No. Description Qty.
10 115-3581 Rod-Brake Release ............................... 1
11 115-3592 Grip 1.0 In .............................................. 1
12 112-8387 Bolt, HH Shoulder 1/4-20 x 1.64 ............ 1
13 117-0375 Spring Torsion LH .................................. 1
14 115-3579 Arm, Brake RH ...................................... 1
15 117-0379 Bolt, Shoulder 1/2-13 x 5.57 .................. 1
16 117-0378 Washer .................................................. 1
17 115-2750 Knob ...................................................... 1
