Exmark LAZER Z Parts Manual

15
PARK BRAKE GROUP
Ref.
No.
Qty.
.Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1 513140 Bushing ................................... 2
16 807020 Woodruff key, 5/16X1............. 2
2
633454 Spring, brake rod..................... 2
17
633268 Grip, brake lever ..................... 1
3
633477 Rod, brake............................... 3
18
800290 Screw, 3/8-16 x 3/4................. 4
4
634500 Lever w/grip............................. 1
19
808285 Pin, clevis 3/8 x 1 1/8.............. 4
632489 Lever, brake ............................ 1
20
800347 Screw, 1/2-13 x 4 (52”&62”).... 8
5
632217 Shaft, brake............................. 1 800334 Screw, 1/2-13 x 6 (72”) ........... 8
6
632714 Bracket, brake (LH) (52”&60”). 1
21
811007 Zerk, 1/4-28 45
°
(52”&60”) ..... 2
632712 Bracket, brake (LH) (72”) ........ 1 811006 Zerk, 1/4-28 straight (72”) ...... 2
7
∗
632715 Bracket, brake (RH)(52”&60”). 1
22
804509 Nut, 1/2-13 .............................. 8
632713 Bracket, brake (RH)(72”)......... 1
23
804525 Nut, 3/8-24 .............................. 8
8
809036 Nut, slotted 1.00-20................. 2
24
809007 Nut, whizlock 3/8-16................ 4
9
633693 Band, brake............................. 2
25
805008 Washer, lock 1/2..................... 8
10
633380 Spacer (short)(52”&60”) .......... 4
26
805260 Washer, 3/8 std ...................... 4
633060 Spacer (short) (72”)................. 4
27
806761 Pin, cotter 1/8 x 3/4................. 9
11
633382 Spacer (long)(52”&60”) ........... 4
28
806800 Pin, cotter 9/64 x 1 1/2............ 2
633062 Spacer (long)(72”)................... 4
29
808283 Pin, clevis 3/8 x 2.................... 2
12
633102 Bearing, flange........................ 2
30
805269 Washer, 3/4 SAE ................... 2
13
633131 Yoke........................................ 4
31
808514 E-Ring, retaining ..................... 2
14 633144 Pin, trunion .............................. 2
32
523157 Washer, spacer ...................... 2
15
★
634927 Hub & drum w/studs, wheel .... 2
633926 Studs, wheel............................ 8
633548 Hub & drum, wheel.................. 2
∗
Not Illustrated

Exmark LAZER Z Specifications

General

Engine Brand	Kawasaki
Transmission	Hydrostatic
Deck Construction	Fabricated or welded steel
Category	Commercial
Type	Commercial
Speed	10 mph
Turning Radius	Zero-turn
Fuel Capacity	10-15 gallons
Weight	1, 465 lbs
