Exmark LAZER Z User Manual

Operation
g223866
Figure6
1.Fuses
4.PTOengagementswitch
2.Messagedisplay5.Throttle
3.Ignitionswitch
6.Choke
ThrottleControl
(AllUnitsExceptREDEquipped
Units)
Locatedonrightconsole(redlever)(seeFigure6and
Figure7).
Thethrottleisusedtocontrolenginespeed.Moving
thethrottleleverforwardwillincreaseenginespeed
andmovingthethrottlelevertotherearwilldecrease
enginespeed.Movingthethrottleforwardintothe
detentisfullthrottle.
g223877
Figure7
1.Fuses4.Ignitionswitch
2.Messagedisplay5.Throttle
3.PTOengagementswitch
REDEquippedLogicDisplayUnit
(LDU)
Locatedontherightconsole.
g293091
Figure8
1.REDEquippedLogic
DisplayUnit(LDU)
4.Deckliftswitch-Wing
deckmodelsonly(also
foldswings)
2.PTOengagementswitch
5.Audiblealarm
3.Ignitionswitch
TheREDEquippedLogicDisplayUnit(LDU)
monitorsanddisplaysmachinesysteminformation.
g030160
Figure9
LDU(LogicDisplayUnit)
1.Informationscreen
3.Pushbuttons
2.LEDstatuslight
28

Exmark LAZER Z Specifications

General

Engine Brand	Kawasaki
Transmission	Hydrostatic
Deck Construction	Fabricated or welded steel
Category	Commercial
Type	Commercial
Speed	10 mph
Turning Radius	Zero-turn
Fuel Capacity	10-15 gallons
Weight	1, 465 lbs
