Exmark LAZER Z User Manual

Operation
Note:Brakemustbeengaged,motioncontrol
leversout(neutrallockposition)andPTOswitch
disengagedtostartengine.(Itisnotnecessaryforthe
operatortobeintheseattostarttheengine.)
Note:TheLCDindicatorsappearwheneachcontrol
meetsthe“safetostart”mode(e.g.theindicator
turnsonwhentheoperatorisintheseat.)
Note:REDEquippedModelsOnly:Thesystem
willallowtheunittostartwiththePTOswitchin
thepulledout(up)position,butwillnotengagethe
blades.ThePTOengagementswitchmustbereset
toengagethePTO.
HourMeter
(ForallLZEModelsandallLZS/LZX
KawasakiModelsExceptRED
EquippedModels)
Locatedontherightconsoleinthemessagedisplay
(referenceFigure6).
Thehourmeterrecordsthenumberofhoursthat
theenginehasrun.
g008612
Figure11
1.LCDIndicators
2.Lowfuelindicatorlight
3.Fuellevelbardisplay
4.Lowvoltageindicatorlight
5.Hour/Voltagedisplay
Thehourmeterisrecordingwhenthedecimalpoint
isashinginHour/Voltagedisplay.
Hoursaredisplayedwhenthekeyisofforwhenthe
machineisrunning.
Note:Iftheignitionkeyisturnedtothe“ON”
positionforafewsecondsbeforecrankingtheengine,
thebatteryvoltagewilldisplayintheareawherethe
hoursarenormallydisplayed.
Note:TheLCDindicatorsappearwheneachcontrol
meetsthe“safetostart”mode(e.g.theindicator
turnsonwhentheoperatorisintheseat.)
HourMeter
(ForLZSKohlerEFIModels)
Locatedontherightconsoleinthemessagedisplay
(referenceFigure7).
Thehourmeterrecordsthenumberofhoursthat
theenginehasrun.
g037701
Figure12
1.Informationscreen
2.LEDstatuslight
Hoursaredisplayedwhenthekeyisofforwhen
themachineisrunning.Thedisplayturnsoffafter
5minutes(refertoHourMeterUser’sGuidefor
moreinformation).
HourMeter
(REDEquippedModels)
LocatedontheinformationscreenoftheRED
EquippedLDUoftheRHconsole(seeFigure8and
Figure9).
Thehourmeterrecordsthenumberofhoursthat
theenginehasrun.
HoursaredisplayedinEngine-Offscreenorinthe
EngineHourCountermenu(refertotheRED
EquippedUser’sGuideformoreinformation).
FuelShut-OffValve
Locatedbehindandbelowtheseat.
30

Exmark LAZER Z Specifications

General

Engine Brand	Kawasaki
Transmission	Hydrostatic
Deck Construction	Fabricated or welded steel
Category	Commercial
Type	Commercial
Speed	10 mph
Turning Radius	Zero-turn
Fuel Capacity	10-15 gallons
Weight	1, 465 lbs
