Exmark LAZER Z User Manual

Operation
g038222
Figure34
AllModelsExceptWingDeck–
SideDischargeModelShown
1.Tie-downlocation
g292532
Figure35
WingDeckModels
1.Tie-downlocation
•OnWingDeckModels,raiseandlocktheouter
wingdecks(seeRaisingandLockingtheOuter
WingDeckssection.
•Secureatrailertothetowingvehiclewithsafety
chains.
WARNING
Drivingonthestreetorroadwaywithoutturn
signals,lights,reectivemarkings,oraslow
movingvehicleemblemisdangerousandcan
leadtoaccidentscausingpersonalinjury.
Donotdrivemachineonapublicstreetor
roadway.
LoadingtheMachine
Useextremecautionwhenloadingorunloading
machinesontoatraileroratruck.Useafull-width
rampthatiswiderthanthemachineforthis
procedure.Backuprampsanddriveforwarddown
ramps(Figure36).
g028043
Figure36
1.Backupramps
2.Driveforwarddown
ramps
Important:Donotusenarrowindividualramps
foreachsideofthemachine.
Ensuretherampislongenoughsothattheanglewith
thegrounddoesnotexceed15degrees(Figure37).
Onatground,thisrequiresaramptobeatleastfour
times(4X)aslongastheheightofthetrailerortruck
bedtotheground.Asteeperanglemaycausemower
componentstogetcaughtastheunitmovesfromthe
ramptothetrailerortruck.Steeperanglesmayalso
causethemachinetotiporlosecontrol.Ifloadingon
ornearaslope,positionthetrailerortrucksothatit
isonthedownsideoftheslopeandtherampextends
uptheslope.Thiswillminimizetherampangle.
48

Exmark LAZER Z Specifications

General

Engine Brand	Kawasaki
Transmission	Hydrostatic
Deck Construction	Fabricated or welded steel
Category	Commercial
Type	Commercial
Speed	10 mph
Turning Radius	Zero-turn
Fuel Capacity	10-15 gallons
Weight	1, 465 lbs
