Exmark Quest 4500-450 - Product Overview; Torque Requirements

ProductOverview
OverallHeight:
AllUnits
41.8inches(106cm)
TreadWidth:(CentertoCenterof
Tires,Widthwise)
42inch
Deck
48inch
Deck
52inch
Deck
Drive
Wheels
36.0inches
(91cm)
36.0inches
(91cm)
36.8inches
(93cm)
Caster
Wheels
27.9inches
(71cm)
33.5inches
(85cm)
33.5inches
(85cm)
WheelBase:(CenterofCasterTireto
CenterofDriveTire)
AllUnits
48.9inches(124cm)
CurbWeight:
42inchDeck48inchDeck52inchDeck
630lb(286kg)645lb(293kg)660lb(299kg)
TorqueRequirements
BoltLocation
Torque
SpindlePulleyNut75-85ft-lb(102-115N-m)
BladeMountingBolt
(lubricatewithanti-seize)
32-42ft-lb(43-57N-m)
EngineMountingBolts
27-33ft-lb(37-45N-m)
Anti-ScalpRollerNyloc
Nut
27-33ft-lb(37-45N-m)
WheelLugNuts
70-90ft-lb(95-122N-m)
ClutchMountingBolt
(securedwiththreadlocker)
50-55ft-lb(68-75N-m)
SparkPlug
15ft-lb(20N-m)
ProductOverview
Figure3
1.Frontcasterwheel8.Engine
2.Anti-scalproller
9.Seat
3.Heightofcutfootlever
10.Armrest
4.Dischargedeector
11.Motioncontrollevers
5.Heightofcutadjustment
12.Parkbrake
6.Reardrivewheel13.Footrest
7.Controlpanel14.Washouttting
