Maintenance
4.Usingaspringremovaltool,(P/N92-5771),
removetheidlerspringfromthedeckhookto
removetensionontheidlerpulleyandrollthe
beltoffofthepulleys(Figure78andFigure79).
WARNING
Thespringisundertensionwheninstalled
andcancausepersonalinjury.
Becarefulwhenremovingthebelt.
g014930
Figure78
34and42InchDecks
1.Idlerpulley
4.Spring
2.Mowerbelt5.Enginepulley
3.Outsidepulley6.Springremovaltool
g237467
Figure79
50and60InchDecks
1.Idlerpulley
4.Spring
2.Mowerbelt5.Enginepulley
3.Outsidepulley6.Springremovaltool
5.Routethenewbeltaroundtheenginepulleyand
mowerpulleys(Figure79).
6.Usingaspringremovaltool,(P/N92-5771),
installtheidlerspringoverthedeckhookand
placingtensionontheidlerpulleyandmowerbelt
(Figure78andFigure79).
InstallingtheMowerDeck
ServiceInterval:Asrequired
1.Parkthemachineonalevelsurfaceanddisengage
thebladecontrolswitch.
2.Movethemotioncontrolleversouttotheneutral
lockposition,engagetheparkingbrake,stopthe
engine,removethekey,andwaitforallmoving
partstostopbeforeleavingtheoperatingposition.
3.Slidethemowerdeckunderthemachine.
4.Lowertheheight-of-cutlevertothelowest
position.
5.Lifttherearofthemowerdeckandguidethe
hangerbracketsovertherearliftrod(Figure77).
62
