Maintenance
ServicingtheFuses
ServiceInterval:Asrequired
Theelectricalsystemisprotectedbyfuses.Itrequires
nomaintenance;however,ifafuseblows,checkthe
component/circuitforamalfunctionorshort.
Fuse:
•MainF1-30amp,blade-type
•ChargeCircuitF2-25amp,blade-type
1.Removeandretainthescrewsecuringthecontrol
paneltothemachine.
2.Liftthecontrolpaneluptoaccessthemainwiring
harnessandfuseblock.
3.Toreplaceafuse,pulloutonthefusetoremove
it(Figure55).
g237377
Figure55
1.Fuse
4.Returnthecontrolpaneltoitsoriginalposition
andsecurethepaneltothemachine.
DriveSystemMaintenance
CheckingtheTirePressure
ServiceInterval:Every25hours/Monthly
(whichevercomesrst)
Maintaintheairpressureinthefrontandreartiresas
specied.Uneventirepressurecancauseunevencut.
Checkthepressureatthevalvestem(Figure56).
Checkthetireswhentheyarecoldtogetthemost
accuratepressurereading.
RearTires:13psi(90kPa)
FrontTires(casterwheels):13psi(90kPa)
g007275
Figure56
1.Valvestem
ChangingtheHydraulic
SystemFilterandOil––50
and60InchS-SeriesOnly
ServiceInterval:Aftertherst75hours
Every500hoursthereafter
(Every250hoursifusing
Mobil115W50thereafter)
Mayneedmoreoften
undersevereconditions.
Thelterandoilarechangedatthesametime.Do
Notreuseoil.Oncethenewlterisinstalledandoil
isaddedanyairinthesystemmustbepurged.
RemovingHydraulicSystemFilters
1.Stopengine,waitforallmovingpartstostop,and
allowenginetocool.Removethekeyandengage
theparkingbrake.
2.Raisetherearofmachineupandsupportwith
jackstands(orequivalentsupport)justhigh
enoughtoallowdrivewheelstoturnfreely.
g237380
Figure57
1.Jackingpoints
53
