Specications
Specications
ModelNumbers
SerialNos:312,000,000andHigher
QTE651KA421;QTE691KA501;QTS691KA502
Systems
Engine
•EngineSpecications:SeeyourEngineOwner’s
Manual
•EngineOilType:Exmark4-CyclePremium
EngineOil
•RPM:
FullSpeed:3300±100(max)RPM(NoLoad)
Idle:1650(min)RPM
FuelSystem
•Capacity:3.0gal.(11.4L)
•FuelRecommendations:
–Forbestresults,useonlyclean,fresh,unleaded
gasolinewithanoctaneratingof87orhigher
((R+M)/2ratingmethod).
–Oxygenatedfuelwithupto10%ethanolor
15%MTBEbyvolumeisacceptable.
–DoNotuseethanolblendsofgasoline(such
asE15orE85)withmorethan10%ethanol
byvolume.Performanceproblemsand/or
enginedamagemayresultwhichmaynotbe
coveredunderwarranty.
–DoNotusegasolinecontainingmethanol.
–DoNotstorefueleitherinthefueltankor
fuelcontainersoverthewinterunlessafuel
stabilizerisused.
–DoNotaddoiltogasoline.
•FuelFilter:
KawasakiP/N49019-7005
ElectricalSystem
•ChargingSystem:FlywheelAlternator
•ChargingCapacity:15amps
•BatteryType:195CCA
•BatteryVoltage:12Volt
•Polarity:NegativeGround
•Fuses:One30amp,one25amp;bladetype
SafetyInterlockSystem
•PTOmustbedisengaged,motioncontrollevers
out(brakeengaged)tostartengine.(Itisnot
necessaryfortheoperatortobeintheseatto
starttheengine.)
•OperatormustbeinseatwhenPTOisengaged
ormotioncontrolleversaremovedinorengine
willstop.
OperatorControls
•SteeringandMotionControl:
Note:Motioncontrolleversareadjustableto
twoheights.
–Separatelevers,oneachsideoftheconsole,
controlspeedanddirectionoftravelofthe
respectivedrivewheels.
–Steeringiscontrolledbyvaryingtheposition
oftheleversrelativetoeachother.
–Movingmotioncontrolleversoutward(in
slots)locksthedrivesysteminneutraland
appliestheparkingbrake.
•PTOEngagementSwitch:Engageselectricclutch
(todrivebelt)whichengagesmowerblades.
•DeckHeightAdjustmentLever:Setscutting
heighttodesiredposition.
•DeckLiftAssistLever:Footpedalthatassistsin
raisingthedeck.
Seat
•Type:
–42inchunit:Standardseatwithhighback,
foampaddedwithspringsuspensionand
armrests.
–50inchunit:Twotoneupholsteredseatwith
springsuspensionandarmrests.
14

Exmark QUEST Specifications

General

Transmission	Hydrostatic
Drive System	2WD
Deck Construction	Fabricated
Fuel Type	Gasoline
Type	Zero-Turn
Deck Material	Steel
Warranty	3 years
