Exmark QUEST - Torque Requirements; Product Overview

ProductOverview
OverallHeight:
AllUnits
41.5inches(105cm)
TreadWidth:(CentertoCenterof
Tires,Widthwise)
42inchDeck50inchDeck
DriveWheels31.5inches
(80cm)
37.4inches
(95cm)
CasterWheels29.5inches
(75cm)
36.9inches
(94cm)
WheelBase:(CenterofCasterTireto
CenterofDriveTire)
AllUnits
45.6inches(116cm)
CurbWeight:
42inchDeck50inchE-Series
Deck
50inchS-Series
Deck
531lb(241kg)614lb(279kg)672lb(305kg)
TorqueRequirements
BoltLocation
Torque
SpindlePulleyNut35-65ft-lb(47-88N-m)
BladeMountingBolt35-65ft-lb(47-88N-m)
EngineMountingBolts
330-400in-lb(37-45N-m)
WheelLugNuts
70-90ft-lb(95-122N-m)
ClutchMountingBolt
(securedwiththreadlocker)
50-60ft-lb(68-81N-m)
ProductOverview
Figure3
1.Frontcasterwheel
8.Controlpanel
2.Anti-scalproller9.Engine
3.Height-of-cutfootlever10.Seat
4.Dischargedeector
11.Fueltank
5.Deckheightadjustment
lever
12.Armrest
6.Washouttting
13.Motioncontrollevers
7.Reardrivewheel14.Footrest
16
