Exmark QUEST User Manual

Operation
TheSafetyInterlockSystem
CAUTION
Ifthesafetyinterlockswitchesaredisconnected
ordamagedthemachinecouldoperate
unexpectedlycausingpersonalinjury.
•Donottamperwiththeinterlockswitches.
•Checktheoperationoftheinterlockswitches
dailyandreplaceanydamagedswitches
beforeoperatingthemachine.
UnderstandingtheSafetyInterlock
System
Thesafetyinterlocksystemisdesignedtopreventthe
enginefromstartingunless:
•Thebladesaredisengaged.
•Themotioncontrolleversareintheneutral
position.
•Theparkingbrakeisengaged.
Thesafetyinterlocksystemisdesignedtoinitiate
engineshutdownwhen:
•Theparkingbrakeisdisengagedandtheoperator
getsoffmachine.
•ThePTOisengagedandtheoperatorgetsoff
machine.
•Theparkingbrakeisdisengagedandleversarein
andtheoperatorgetsoffmachine.
TestingtheSafetyInterlockSystem
Testthesafetyinterlocksystembeforeyouusethe
machineeachtime
1.Checkstartingcircuit.Startershouldcrankwith
thePTOdisengagedandmotioncontrollevers
movedoutintheparkingbrakeposition.The
operatordoesnotneedtobeintheseattostart
theengine.
Trytostartwithoperatorinseat,PTO
disengagedandmotioncontrolleversinthe
parkingbrakeposition-startermustnotcrank.
Trytostartwithoperatorinseat,PTO
disengaged,andtheleftmotioncontrollever
in,startermustnotcrank,repeatagainwiththe
rightleverin,thenwithbothleversin-starter
mustnotcrank.
2.Checkkillcircuits.Runengineatone-third
throttle,engagePTOandraiseoffofseat(but
donotgetoffofmachine)enginemustinitiate
shutdown.
Runengineatone-thirdthrottle,withbrake
disengaged,moveleversinandraiseoffseat(but
donotgetoffofmachine)enginemustinitiate
shutdown.
Note:Ifmachinedoesnotpassanyofthesetests,
DoNotoperate.ContactyourauthorizedEXMARK
SERVICEDEALER.
Important:Itisessentialthatoperatorsafety
mechanismsbeconnectedandinproper
operatingconditionpriortouseformowing.
DrivingForwardorBackward
Thethrottlecontrolregulatestheenginespeedas
measuredinrpm(revolutionsperminute).Place
thethrottlecontrolintheFastpositionforbest
performance.AlwaysoperateintheFast(fullthrottle)
position.
CAUTION
Machinecanspinveryrapidlybypositioningone
levertoomuchaheadoftheother.Operatormay
losecontrolofthemachine,whichmaycause
damagetothemachineorinjury.
•Usecautionwhenmakingturns.
•Slowthemachinedownbeforemakingsharp
turns.
Forward
1.Movetheleverstothecenter,unlockedposition.
2.Togoforward,slowlypushthemotioncontrol
leversforward(
Figure10).
22

Exmark QUEST Specifications

General

Transmission	Hydrostatic
Drive System	2WD
Deck Construction	Fabricated
Fuel Type	Gasoline
Type	Zero-Turn
Deck Material	Steel
Warranty	3 years
