Exmark QUEST User Manual

Operation
thepositionsshowninFigure15.Rollerswill
maintain3/4inches(19mm)clearancetothe
groundtominimizegougingandrollerwearor
damage.
Note:ForMaximumDeckFlotation,place
therollersoneholepositionlower.Rollersshould
maintain1/4inch(6.35mm)clearancetothe
ground.DoNotadjustrollerstosupportthe
deck.
Figure14
42InchDeck
1.Anti-scalprollermountingbracket
2.Below21/2inches(64mm)cuttingheight
3.21/2inches(64mm)andabovecuttingheight
Figure15
50InchDeck
Forcuttingheightsabove31/2inches(90mm)
usethebottomhole.Therollerswillstillbeeffective
againstscalping.
1.Anti-scalproller
mountingbracket
2.Cuttingheight
7.Torquehardwareto27-33ft-lb(37-45N-m)or
lossofrollermayresult.
PositioningtheSeat
Theseatcanmoveforwardandbackward.Position
theseatwhereyouhavethebestcontrolofthe
machineandaremostcomfortable.
•42InchUnit:
1.Tiptheseatforward.
2.Loosentheadjustmentbolts.
G014477
1
Figure16
1.Adjustmentbolt
3.Movetheseattothedesiredpositionand
tightenbolts.
4.Tiptheseatbacktotheclosedposition.
•50InchUnits:
1.Pushtheadjustmentlevertowardsthecenter
ofthemachinetoreleasetheseatadjuster
track(
Figure17).
Figure17
1.Adjustmentlever
2.Movetheseattothedesiredpositionand
releasethelevertolockinthatposition.
25

Exmark QUEST Specifications

General

Transmission	Hydrostatic
Drive System	2WD
Deck Construction	Fabricated
Fuel Type	Gasoline
Type	Zero-Turn
Deck Material	Steel
Warranty	3 years
