Exmark Turf tracer HP Setup Instructions

InstallingtheFuelTank
1.Applyretainingadhesive“Fel-ProProLockRetaining
IorRetainingII”or“LoctiteRC609or680”onthe
twothreadedstudsfromtheboltbagandinstallinto
thetwoleftholesunderneathfueltank.Installthe
fueltankontopofthefueltanksupportwiththe
studsgoingthroughtheslotsinthesupport.
2.Installtwo5/16x3/4inchscrewswitha5/16inch
SAEatwasherand5/16inchlockwasherintothe
threadedholesintherightsideofthefueltank.Do
Notovertighten.
3.Placea5/16inchSAEatwasher,thenaspring,
overeachofthestudsandfastenwitha5/16inch
nylocnut.Tighten5/16inchnylocnutfullythen
backoffa1/2turn.Thisistoallowfornormal
fueltankexpansionandcontractionwithchangesin
temperatureandfuellevels.Donotovertighten.
4.Attachthefueltankhosetothetankttingand
securewiththeclampprovided.
InstallingtheFuelTank(CAUnits
Only)
1.Installthefueltankontopofthefueltanksupport.
Secureeachsideofthetankwithaclamp,5/16-18x
2screw,washer,and5/16nylocnut.
2.Attachthepurgehosefromthecanistertothetop
ttingofthefueltankasshownin
Figure1.
Figure1
1.Attachpurgehosefromcanistertotoptting
3.Attachthefueltankhosetothetankttingand
securewiththeclampprovided.
InstallingtheHandleAssembly
1.Positionthelowerendofthehandleassemblyon
theoutsideoftheupperrearsectionofthefueltank
andhandlesupport.
2.Installfour3/8-16x1inchbolts,fourspringdisk
washersfromtheoutsidein.Secureusingfour
3/8-16whizlocknutsontheinsideofeachhandle
supportandtightenuntilthespringdiskwashersare
at(Figure2).
Note:Besuretheconeofthespringdiskwasheris
againsttheheadofthebolt.
Figure2
1.Frontoftheunit
3.Upperhandle
2.Upperhandlemounting
tab
AttachingtheThrottleCable
1.Routethethrottlecablealongtherightsideofthe
upperhandle,underthefueltanksupport,and
positionthecableontheleftsideoftheengine.
2.Positionthethrottlecontrollever(locatedonthe
console)inthefullthrottleposition.Youwillfeela
detentwhenthethrottleleverispushedtowardsthe
upperendoftheslot.
3.Attachtheinnerwireofthethrottlecabletothe
topholeinthethrottlecontrolleverasshownin
Figure3.
4.Loosentheclamp,installthethrottlecableonthe
bottomsideoftheclamp,andpullonthecableto
movethethrottlelinkagetothefullthrottleposition.
Tightenthecableclampscrew .
2
