Exmark Turf tracer HP Setup Instructions

LubricationChart
Fitting
Locations
Initial
Pumps
Numberof
Places
Service
Interval
6.PumpControl
Bearings
22
40hours
7.MowerDeck
IdlerPivots
21
Yearly
Number4(PumpDriveIdlerPivot)Locatedunder
theenginedeck.
Number5(ClutchArmPivot)Locatedunderthe
enginedeck.
Figure8
2.LubricatethepivotpointonPTOleverwithaspray
penetratinglubricant.
ServicingtheEngine
RefertoEngineOwner’sManual.
ServicingtheHydraulicOil
Themachineisshippedwithhydraulicoilinthe
reservoir.
1.Runthemachineforapproximately15minutesto
allowanyextraairtopurgeoutofthehydraulic
system.
2.Checkhydraulicreservoirandifnecessaryllthe
reservoirtotheappropriatelevelwithExmark
PremiumHydrooil.
3.Replacehydraulicreservoircapandtightenuntil
snug.DoNotovertighten.
Note:Thebafeislabeled“HOT”and“COLD”.
Theoillevelvarieswiththetemperatureoftheoil.
The“HOT”levelshowsthelevelofoilwhenitisat
225°F(107°C).The“COLD”levelshowsthelevelof
theoilwhenitisat75°F(24°C).Filltotheappropriate
leveldependinguponthetemperatureoftheoil.For
example:Iftheoilisabout150°F(65°C).Filltohalfway
betweenthe“HOT”and“COLD”levels.Iftheoilisat
roomtemperature(about75°F(24°C)),llonlytothe
“COLD”level.
FillingOuttheProduct
Registration
Fillouttheonlinewarrantyregistrationformandplace
keysintoliteraturepack.
7
