Exmark Turf tracer HP Setup Instructions

eitherdirection,thelengthofthedriveleverlinkwill
needtobeadjusted.
3.Adjustthelinkagelengthbylooseningthejamnuts
atbothendsofthelinkageandrotatingthelinkage
intheballjoints.Lengthenthelinkageifthetireis
turninginreverseandshortenthelinkageifthetire
iscreepingforward.Tightenthejamnutsatboth
ends.Releaseandre-engagetheneutrallocklatch
checkingthatthetirestops.Continuethisprocess
untilthetirenolongerrotates.
Figure7
4.Makethisadjustmentforbothsides.
ConnectingWireHarness
Forrecoilstartmodels:
1.Routethelong,unattachedwiringharnesslead
upthelefthandsideofthehandleandunderthe
console.
2.Connecttheconnectorontheendoftheshorter
leadtothekeyswitch.
3.ConnectthetwoagterminalstotheOPCswitch
inanyorder.
4.Continueroutingthisleaddowntherightsideofthe
handleandconnecttheconnectorontheendtothe
parkbrakeswitch.
5.Fastentheharnesstotheleftsideofhandlewithtwo
largeplastictiesfromtheboltbag.
6.Fastentheharnesstotherighthandsideofthe
handleusingtwosmalltiesfromtheboltbag.
7.Fastentheharnesstothetwosmallholesinthe
channelundertheconsoleusingtwosmalltiesfrom
theboltbag.
Forelectricstartmodels:
1.Routethelong,unattachedwiringharnesslead
upthelefthandsideofthehandleandunderthe
console.
2.ConnectthetwoagterminalstotheOPCswitch
inanyorder.
3.Connecttheconnectortothekeyswitch.
4.Fastentheharnesstotheleftsideofhandlewithtwo
largeplastictiesfromtheboltbag.
5.FastentheleadsconnectingtotheOPCswitchto
thesmallholeinthechannelundertheconsoleusing
asmalltiefromtheboltbag.
ServicingtheBattery
WARNING
CALIFORNIA
Proposition65Warning
Batteryposts,terminals,andrelated
accessoriescontainleadandleadcompounds,
chemicalsknowntotheStateofCalifornia
tocausecancerandreproductiveharm.
Washhandsafterhandling.
Important:Themachineisshippedwithalled
leadacidbattery.
DANGER
Chargingorjumpstartingthebatterymayproduce
explosivegases.Batterygasescanexplodecausing
seriousinjury.
•Keepsparks,ames,orcigarettesawayfrom
battery.
•Ventilatewhenchargingorusingbatteryinan
enclosedspace.
•Makesureventingpathofbatteryisalwaysopen
oncebatteryislledwithacid.
•Alwaysshieldeyesandfacefrombattery.
5
