SAIC Exploranium – GR-135 System Manual page: 17
5.6 STABILIZATION
The GR-135 is designed to automatically carry out system stabilization in the AUTOMATIC mode in
the DOCKING STATION. Once this has been done correctly then internal temperature correction is
used to maintain this level even if the unit has not been stabilized for many hours.
However in the MANUAL mode the system must be stabilized manually using the functions
described in section 7.
If the unit decides that Stabilization is required then a STABILIZATION WARNING display will be
shown – see Fig. 5.
If DEFAULT PARAMETERS are loaded then this warning will be seen as Stabilization is required
before the SEARCH and IDENTIFY functions.
Fig. 5
5.7 EXTERNAL AUDIO
On the rear of the unit is a special connector as
shown in the rear view of the instrument shown in
the figure (external audio). Normally this
connecter is fitted with a sealing plug for weather
protection. However users with the optional
external earphone can plug it into this socket.
When this occurs the internal audio is silenced and
the audio tones are only audible through the
external earphone.
This silencing of the units audio is especially useful
in covert audio scanning or when the operator
does not wish to alarm anyone with sudden audio
tone increases
IT IS EXTREMELY IMPORTANT THAT
STABILIZATION BE CARRIED OUT IF REQUIRED
AFTER LOADING DEFAULT PARAMETERS - THE ACT
OF STABILIZATION SETS ALL THE SYSTEM
COMPUTATIONAL REQUIREMENTS FOR CARRYING
OUT THE IDENTIFY FUNCTION. WITHOUT THIS
STABILIZATION SERIOUS DATA ANALYSIS ERRORS
WILL OCCUR!
SEE THE FOLLOWING SECTIONS
FOR DETAILS ON OTHER FUNCTIONS
EXTERNAL
AUDIO
