9.2 DUMP
DUMP is a utility for outputting data stored in the GR135 memory to an external utility program
such as the Exploranium supplied PC utility program IdentiView (described in Appendix B). .
Selecting DUMP allows the user to transfer stored Survey, Dose and Spectral data to an external
PC via the data transfer cable from the DS unit. It is critical that the GR-135 be turned OFF
before connecting the unit to the data transfer cable. If the unit remains ON, any shock or
power surge arising from the connection may corrupt data in memory.
User may use such utilities as HyperTerminal to output the stored data however the majority of
the stored data is in a Binary format so the user must have special conversion utilities to convert
the data in the format they require.
Note the RS232 port is configured as :
- Baud = 19200
- Data bits = 8
- Parity = none
- Stop bit = 1
- Flow control = none
Selecting DUMP will produce the display shown in fig. 27. When
the appropriate PC software is operating, data may be transferred
by CLICK DOWN. Pushing the button up will cancel
this function. When data transfer is complete Fig. 27
9.3 ERASE
Selecting this function produces a new display. The display shows:
Pressing the button down three times erases the data memory completely. The first two times the
button is pressed, the word CLEAR should appear at the bottom of the display.
Users Are Warned That Erased Data Cannot Be Recovered!
9.4 MEM SCAN
This selection lets the user inspect and re-analyze spectra previously stored in memory.
If this option is selected, the first spectrum in memory summary is displayed. For example:
Note the DATE is in YY – MM – DD format
The user must CLICK LEFT/RIGHT to select the required spectrum. The spectrum number is the
same one used as a label during the spectrum store. The Date/Time of the recorded spectra are also
provided for reference.
TO DUMP MEMORY
PUSH BUTTON DOWN
OR UP TO QUIT
DATA MEMORY
PUSH ENTER THREE TIMES
TO ERASE MEMORY
OR ONCE UP
TO QUIT
SPECTRUM #1
DATE 02 01 18
TIME 12 36 50
