CG206‐en‐GB_v1.06/16

WORKINGMODE

1. PresstheLEFTbutton(SEL)toaccessthemenu.

2. ScrolltoWORKINGMODE(ifnecessary)usingup/downbuttons.

3. PresstheLEFTbutton(SELECT)toopenWORKINGMODE.

4. UsetheUPandDOWNbuttonstoscrollthroughthegroupsandtoseethenumberofsaved

readingsin

eachgroup.Group0doesnothavememory.

5. PresstheLEFTbutton(SELECT)toselectthegroupandexitWorkingmode andreturntothe

mainmenuorpresstheRIGHTbutton( )twicetoreturntothenormaloperatingmode.



MEASUREMODE

1. PresstheLEFTbutton(SEL)toaccesstheprogrammingmenu

2. UsetheUP/DOWNbuttonstoscrolltotheMeasureMode

3. PresstheLEFTbutton(SELECT)toselecttheMeasureMode

4. UsetheUP/DOWNbuttonstoscrolltoAuto,FE,orNFE.

PresstheLEFTbutton(SELECT)to

makeaselection.

AUTOmode‐themeterautomaticallyrecognizesthemetalthatisbeingmeasured.

Ferrous(FE)Mode‐theMagneticinductionmeasurementmodeisused.

Non‐Ferrous(NFE)Mode‐theeddycurrentmeasurementmodeisused.

5. PresstheRIGHTbutton(

) toreturntothe normaloperatingmode.



SET

1. PresstheLEFTbutton(SEL)toaccessthemenu.

2. UsetheUP/DOWNarrowstoscrolltoSET.

3. PresstheLEFTbutton(SELECT)toopentheSETmenu.

4. UsetheUPandDOWNbuttonstoscrollthroughtheselections.

5. PresstheLeftbutton(SELECT)toopentheselecteditem.

a. Unitsofmeasureselections

Selectµmormilusingthearrowbuttons(µm=micrometers;mils).PresstheLEFT

button(SELECT)buttontoconfirmandtoreturntotheSETmenu(otherwisepressthe

rightbutton(

) toaborttheeditandreturntotheSETmenu).

b. Backlight

UsetheUPandDOWNarrowstoadjustthebrightnessofthebacklight.

PresstheRIGHTbutton(

)toconfirmandreturntothe SETmenu.


