7

c. AutoPowerOFF
SelectENABLEorDISABLEusingthearrowbuttons.Whenenabled,themeter
automaticallyswitchesOFFafter3minutesofinactivity.Whendisabled,themeterwill
onlyswitchOFFwitha powerbuttonpressorwhenthebatterypowerisweak.
PresstheLEFTbutton(SELECT)buttontoconfirmandtoreturntotheSETmenu
(otherwisepresstherightbutton( ) toabortthe editandreturntotheSETmenu).

d. Contrast
UsetheUPandDOWNarrowstoadjustthedisplaycontrastupordown.
PresstheLEFTbutton(OK)buttontoconfirmandtoreturntotheSETmenu
(otherwisepresstherightbutton( )toaborttheeditandreturntotheSETmenu).

e. Info
Themodelnumberandfirmwareversionlevelaredisplayed.
Presstherightbutton( ) toexittotheSETmenu.


MEASUREVIEW
TheMeasureViewmenuallowsforscrollingthroughthereadingsinallofthegroups.
Readingscanbeviewedordeletedinthismode.
1. PresstheLEFTbutton(SEL)toaccessthemainmenu.
2. UsetheDOWNARROWbuttontoscrolldowntoMEASUREVIEW.
3. PressLEFT(SELECT)
toopentheMEASUREVIEWparameter.
4. UsetheUP/DOWNARROWbuttonstoscrollthroughthegroupsofstoredreadings.
5. Whenagroupishighlightedthatcontainsstoredreadings,usetheLEFT(SELECT)buttonto
openthereadingslist.NowusetheUP/DOWNarrowstoviewthereadings.Press
theLEFT
button(DeleteGroup)todeleteallreadingsinthisGrouporpresstheRIGHTbutton(
) to
returntothemainGrouplist.
6. Highlight‘DeleteAll’andpresstheLEFTbutton(SELECT)todeleteallofthereadingsinall
groups.OtherwisepresstheRIGHTbutton( )toreturntothepreviousmenu.
