CG206‐en‐GB_v1.06/16

CALIBRATION

TheCalibrationmenuallowstheusertoperformaFerrous(ZeroFE)ornon‐ferrous(ZeroNFE)

ZEROCalibration.TheCalibrationmenualsoallowstheusertodeleteZEROcalibrationdatafor

bothferrous(ZeroF)andnon‐ferrous(ZeroN)modes.

1. PresstheLEFTbutton(SEL)toaccessthe

mainmenu.

2. UsetheDOWNbuttontoscrolltoCALIBRATION.

3. PressLEFT(SELECT)toopentheCALIBRATIONparameter.

4. ToperformaZEROCalibration,refertoZeroCalibrationinthenextsection.

5. TodeleteZEROCalibrationdata,scrolltoDELZeroofFEorDELZeroof

NFEandthenpress

theLEFTbutton(SELECT).ThisexecutestheZerodeletefunctionandreturnsthemeterto

theSETmenu.

6. PresstheRIGHTbutton( ) toreturntothe normaloperatingmode.



ReferenceFilmAccuracyVerification

1. TheCG206metercomeswithasetofreferencefilmstocheckthemeasurement

accuracyofthemeter.

2. ThebasematerialsareFerrous(Steel)andtheNon‐Ferrous(Aluminum).

3. Turnonthemeter1meterawayfromanymaterial.

4. SettheMeasureModetoFE,NFE,or

Auto.

5. PerformaZerocalibrationonthebasematerialofyourchoice.

6. Placeathicknessfilmonthebaseandmakeameasurement.

7. Refertotheaccuracyspecificationstovalidatetheaccuracyofthemeter.
