CHAPTER 24
PAGE 6
MAINTENANCE MANUAL EXTRA 300/SC
PAGE DATE: 16. June 2008
24-30-02 Master Relay
Removal/Installation
N O T I C E Ensure the master switch is in Off-position.
1 Remove the main fuselage cover as per Chapter 51-00-
01.
2 Disconnect electrical wiring.
3 Remove the DIN933 M5x12 attachment bolts, the
DIN9021 M5x20 washers and the LN9348-05 stopnuts.
4 Remove the master relay.
5 Install in reverse sequence of removal.
