Extra 300/SC - Chapter 53 Fuselage

MAINTNANCE MANUAL EXTRA 300/SC
PAGE DATE: 1. August 2014 CHAPTER 53
PAGE 2
Table of Contents
Chapter Title
Chapter 53
53-00-00 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Figure 1 Fuselage Steel Tube Design . . . . . . . . . . . . . . . . . . . . . 4
Figure 2 Layer Sequence Top Half of the Engine Cowling . . . . 5
Figure 3 Layer Sequence Bottom Half of the Engine Cowling . . 6
Figure 4, Sheet 1 Layer Sequence Main Fuselage Cover . . . . . . . . . . . . 7
Figure 4, Sheet 2 Layer Sequence Main Fuselage Cover . . . . . . . . . . . . 8
Figure 5 Layer Sequence Side Cover . . . . . . . . . . . . . . . . . . . . . 9
Figure 6 Layer Sequence Side Cover . . . . . . . . . . . . . . . . . . . . 10
53-00-10 Canopy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
53-00-11 Canopy Glass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Figure 7 Typical cross section of canopy bonding area . . . . . . 11
Figure 8 Canopy position markings . . . . . . . . . . . . . . . . . . . . . 12
Figure 9 Canopy tape markings . . . . . . . . . . . . . . . . . . . . . . . . 12
Figure 10 Canopy adhesive remainders . . . . . . . . . . . . . . . . . . . 13
53-00-04 Bottom Fuselage Cover . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 11 Forward View on Bottom Side Firewall . . . . . . . . . . . 15
