CHAPTER 51
PAGE 3
MAINTENANCE MANUAL EXTRA 300/SC
PAGE DATE: 16. June 2008
51-00-00 GENERAL
51-00-01 Access Panel Identification
For the EXTRA 300/SC all removable covers and fairings are
defined as access panels (refer to Figure 1 and the adjacent
chart). If maintenance or repair is not restricted to a small
area it is advisable to remove all access panels before
beginning work or checks.
N O T E Access panels partly overlap. Remove the front panels
first.
All panels are screwed.
Unscrew the upper instrument panel attachment screws and
the filler neck screws before removal of the main fuselage
cover.
For the removal/installation of the wing tip panels refer to
Chapter 57.
Prior to unscrewing of the air inlet screen remove bottom
half of the engine cowling not to lose the attachment stopnuts
and washers.
