CHAPTER 32
PAGE 6
PAGE DATE: 1. August 2014
MAINTENANCE MANUAL EXTRA 300/SC
32-10-04 Tail spring
Removal/Installation
Refer to Figure 3.
1 Shore the tail as per Chapter 07-20-02.
2 Remove the tail cone access panel as per Chapter 51-00-
01.
3 Remove the tail spring attachment bolts (1-3).
4 Remove the tail spring (4).
5 Reverse procedure for installation; consider to fasten the
breather line using the MS21919-DG12 clamp (5).
32-10-05 Tail Wheel Fork Assembly
Disassembly/Assembly
1 Shore the tail as per Chapter 07-20-02.
2 Remove the elastic stop nut and the large washer.
3 Remove the locking pin, spring, and spare retaining pin.
4 Reverse procedure for assembly.
32-10-06 Tail Wheel
Disassembly/Assembly
1 Shore the tail as per Chapter 07-20-02.
2 Remove the attachment bolt, washers, and stop nut.
3 Remove the tailwheel.
4 Disassemble the bearings, the wheel halves, the spacer
sleeve, and the solid ruber tire.
5 Reverse procedure for assembly.
MAINTENANCE PRACTICES
Top Half of the Mounting Clamp
