Extra 300/SC - Wheel Axis

CHAPTER 32
PAGE 5
PAGE DATE: 1. August 2014
MAINTENANCE MANUAL EXTRA 300/SC
Figure 2 Main Landing Gear Mounting
32-10-03 Wheel Axis
Removal/Installation
1 Remove wheel fairing as per chapter 32-40-02.
2 Remove wheel.
3 Remove the four wheel axis attachment bolts and remove
the axis, the reinforcement plate and the wheel fairing holder
plate.
4 Install in reverse sequence of removal. Use new nuts and
bolts.
