CHAPTER 24
PAGE 8
MAINTENANCE MANUAL EXTRA 300/SC
PAGE DATE: 16. June 2008
24-60-02 Lever Switch
Removal/Installation
N O T I C E Disconnect battery
1 Remove the Main fuselage cover as per Chapter 51.
2 Disconnect wiring from the switch.
3 Remove the attachment nut at the front side of the in-
strument panel.
4 Remove the switch.
5 Install in reverse sequence of removal.
24-60-03 Subminiature Pushbutton Switch
Removal/Installation
N O T I C E Disconnect battery
1 Remove the attachment nut.
2 Tie out the switch some centimeters.
3 Loosen the soldered connections.
4 Remove the switch.
5 Install in reverse sequence of removal.
